| apply | Fragile, soil, fiber, strong oxidation, corrosive powder
pollution-free grinding | application area | Medicine, medicine, food, chemicals, synthetic materials,
electronics, engineering, metallurgy, glass |
| sample characteristic | Soft / hard material, brittle material | The principle of crushing | Friction force, collision force |
| Milling method | Dry method or wet method | cryogrinding | customizable |
| Vacuum grinding | yes | Conventional crushing time | 10-25min |
| Feed size | Crisp material <12mm; remaining material <4mm | Finishing particle size | 0.1um |
| Maximum grinding amount of the batch | 2L/1L/0.4L | Number of grinding platforms | 4pcs |
| ratio of transmission | 1:-2 | Ball grinding tank speed | 580r/min |
| Speed adjustment range of the space rotating mechanism | (8-12)r/min | Ball grinding tank type | utility-type |
| noise | 60-75 db (depending on the ground ball and sample placed in the
ball grinding tank) | Ball grinding tank material | Stainless steel / nylon / polyurethane / teFE / polypropylene /
polyethylene / agate / alumina / zirconia, etc |
| Ball grinding tank size | 500ml/250ml/100ml | Grinding ball material | Stainless steel / alumina / zirconia / calcium carbide, etc |
| Grinding ball size | 2-30mm | operator schema | High touch touchscreen (standard) |
| Touch screen function |
| Ball grinding tank program running aspects | Manual operation: can be forward, reverse, stop, manually setting
speed and other routine functions | Program operation: 5 period speed of operation can be to run
forward (time can be set), reverse running (time can be set),
alternating running, intermittent running (time can be set),
regular grinding (time), pause, program period and time monitoring,
also for customers to write, read call custom formula more human
function choice; |
| Protection function: have program memory, power failure memory,
fault code prompt and other auxiliary protection functions to
ensure the customer requirements |
| The program operation aspect of the space rotation mechanism | Manual operation: the flipping can be manually started and stopped
at any angle |
| Procedure operation: it can realize the delay start with the ball
grinding tank program, and can track the practical functions such
as starting, stop, and pause of the ball grinding tank program
consistent with each other, so that the mutual integration of the
two programs, and truly achieve the static advanced command |
| Grinding time setting | Numbers display, 00:00:01 to 99:59:59 | Pause time setting | Numbers display, 00:00:01 to 99:59:59 |
| Interval operation time setting | Numbers display, 00:00:01 to 99:59:59 | drive | Frequency converter, three-phase AC motor |
| driving power | 0.75kw | driving voltage | 220V |
| Motor frequency | 50Hz | mains connections | uniphase |
| Body effective size (width * depth * height) | 1000*700*595 | Maximum body size (width * depth * height) | 1092*724*673 |
| net weight | About 196kg (no tank and pendant weight) | standard | CE |
